รายละเอียดสินค้า:
|
| Product Name: | Piling Rig Machine | Max Drilling Diameter: | 1000 |
|---|---|---|---|
| Max Torque: | 300 | Max Drilling Depth: | 23(17+6) |
| Main Winch Force: | 320 | Crownd Force: | 220 |
| Stroke: | 17 | Base Engine: | CAT C-9 |
| Highlight: | Diesel Engine Piling Rig,320KN Drilling Rig Machine,KR300C Piling Rig Machine | ||
| Technical specification of KR300C rotary drilling rig | |
| Torque | 300kN.m |
| Max. diameter | 2200 mm |
| Max. drilling depth | 80/54 m |
| Speed of rotation | 7~23 rpm |
| Max. crowd pressure | 260 kN |
| Max. crowd pull | 260 kN |
| Main winch line pull | 340 kN |
| Main winch line speed | 72 m/min |
| Auxiliary winch line pull | 90 kN |
| Auxiliary winch line speed | 70 m/min |
| Stroke(crowd system) | 6000 mm |
| Mast inclination(lateral) | ±5° |
| Mast inclination(forward) | 5° |
| Max. operating pressure | 34.3 MPa |
| Pilot pressure | 3.9MPa |
| Travel speed | 1.5 km/h |
| Traction force | 510 kN |
| Operating height | 22685 mm |
| Operating width | 4300 mm |
ผู้ติดต่อ: Ms. Camilla
โทร: +86 18352067788
แฟกซ์: 86-510-83590757
